3 MECHANICAL VALVES - MINIATURE

TECHNICAL DATA Push-in fitting for pipe diam.
Valve fitting port 4mm Tube or M5 Thread
Filtered air without lubrication;
Fluid lubrication, if used,
must be continuous
with poppet
Type 0.5 - 10 bar
Operating pressure -10% ÷ +60˚C
Operating temperature range 2.5mm
Nominal diameter 16.5 NI/min - bar
Conductance C 0.003 bar/bar
Critical ratio b 35 NI/min
Flow rate at 6 Bar P 0.5 Bar 60 NI/min
Flow rate at 6 Bar P 1 Bar 8N
Actuation force - Plunger at 6 Bar ISO and UNI FD22
Recommended lubricant In any position
Installation

“VME” ROLLER VALVE

CODE DESCRIPTION FIG. SYMBOL €

W3501000200 3/2 Way Norm. Closed 4mm Fittings at Bottom A P06
W3501001201 3/2 Way Norm. Closed 4mm Fittings at Side B
W3501000211 3/2 Way Norm. Closed M5 Ports at Bottom A 16.10
W3501001211 3/2 Way Norm. Closed M5 Ports at Side B 17.03
W3501000201 3/2 Way Norm. Open 4mm Fittings at Bottom C 15.75
W3501001200 3/2 Way Norm. Open 4mm Fittings at Side D 16.68
W3501000210 3/2 Way Norm. Open M5 Ports at Bottom C 17.48
W3501001210 3/2 Way Norm. Open M5 Ports at Side D 18.37
17.11
18.01

SEE NEXT PAGE FOR DIMENSIONS

“VME” ONE WAY ROLLER VALVE

CODE DESCRIPTION FIG. SYMBOL €

P06

W3501000300 3/2 Way Norm. Closed 4mm Fittings at Bottom E 17.33

W3501001301 3/2 Way Norm. Closed 4mm Fittings at Side F 18.25

W3501000311 3/2 Way Norm. Closed M5 Ports at Bottom E 16.95

W3501001311 3/2 Way Norm. Closed M5 Ports at Side F 17.90

SEE NEXT PAGE FOR DIMENSIONS

“VME” PLUNGER VALVE

CODE DESCRIPTION FIG. SYMBOL €

P06

W3501000100 3/2 Way Norm. Closed 4mm Fittings at Bottom I 13.67

W3501001101 3/2 Way Norm. Closed 4mm Fittings at Side J 14.59

W3501000111 3/2 Way Norm. Closed M5 Ports at Bottom I 13.30

W3501001111 3/2 Way Norm. Closed M5 Ports at Side J 14.22

W3501000101 3/2 Way Norm. Open 4mm Fittings at Bottom G 14.98

W3501001100 3/2 Way Norm. Open 4mm Fittings at Side H 15.94

W3501000110 3/2 Way Norm. Open M5 Ports at Bottom G 14.62

W3501001110 3/2 Way Norm. Open M5 Ports at Side H 15.50

SEE NEXT PAGE FOR DIMENSIONS
