3 MECHANICAL VALVES - MINIATURE

Material Nominal flow rate at 5 bar 100NI/min

Body Aluminium 11S Temperature range max + 60°

Spring Stainless Steel Working pressure 2 ... 10 bar, 2 ... 1 MPa

Seals NBR Actuating Force 6N

Internal Parts Brass OT58 Fluid 50µ filtered, lubricated or non lubricated air

Nominal Orifice 2.5mm

MANUAL ACTUATOR ADAPTOR ROLLER LEVER VALVE

for Plunger Valves M5 Ports or 4mm Fittings

CODE DESCRIPTION € CODE DESCRIPTION SYMBOL €

N17 N17

08.017.2 Single 1.62 305MR 3/2” NC M5 Ports 15.37

08.015.2 Double 1.62 315MR 3/2” NO M5 Ports 16.84

304MR 3/2” NC 4mm Fittings 17.47

314MR 3/2” NO 4mm Fittings 18.95

PLUNGER VALVE UNIDIRECTIONAL LEVER VALVE

M5 Ports or 4mm Fittings M5 Ports or 4mm Fittings

CODE DESCRIPTION SYMBOL € CODE DESCRIPTION SYMBOL €

N17 N17

305MA 3/2” NC M5 Ports 12.21 305MS 3/2” NC M5 Ports 16.84

315MA 3/2” NO M5 Ports 13.90 315MS 3/2” NO M5 Ports 18.74

304MA 3/2” NC 4mm Fittings 14.32 304MS 3/2” NC 4mm Fittings 18.95

314MA 3/2” NO 4mm Fittings 16.00 314MS 3/2” NO 4mm Fittings 20.85

PANEL MOUNTED PLUNGER VALVE VALVE FOR MANUAL ACTUATOR

M5 Ports or 4mm Fittings M5 Ports or 4mm Fittings

CODE DESCRIPTION SYMBOL € CODE DESCRIPTION SYMBOL €

N17 N17

305MV 3/2” NC M5 Ports 13.48 305MB 3/2” NC M5 Ports 13.69

315MV 3/2” NO M5 Ports 15.16 315MB 3/2” NO M5 Ports 15.37
304MV 3/2” NC 4mm Fittings 15.58
304MB 3/2” NC 4mm Fittings 15.79

314MV 3/2” NO 4mm Fittings 17.27 314MB 3/2” NO 4mm Fittings 17.47

TOGGLE LEVER VALVE 5/2 VALVE FOR MANUAL ACTUATOR

Brass M5 Ports or 4mm Fittings

CODE DESCRIPTION SYMBOL € CODE DESCRIPTION SYMBOL €

N17 N17

305LL M5 Ports 19.68 504MBCU 5/2” 4mm Fittings 30.11

5/3 VALVE FOR MANUAL ACTUATOR

M5 Ports or 4mm Fittings

CODE DESCRIPTION SYMBOL €

N17

2.304MBCU 5/3” 4mm Fittings 28.63
