MECHANICAL VALVES - MINIATURE 3

“VME” PUSH BUTTON ADAPTOR

CODE DESCRIPTION €

0351000050 For Plunger Valves P06

SEE BELOW FOR DIMENSIONS 2.01

“VME” PANEL MOUNTED PLUNGER VAVLE

CODE DESCRIPTION FIG. SYMBOL €

P06

W3501000400 3/2 Way Norm. Closed 4mm Fittings at Bottom K 14.59

W3501001401 3/2 Way Norm. Closed 4mm Fittings at Side L 15.48

W3501000411 3/2 Way Norm. Closed M5 Ports at Bottom K 14.24

W3501001411 3/2 Way Norm. Closed M5 Ports at Side L 15.15

SEE BELOW FOR DIMENSIONS

Ø4 M5 Ø4 M5 Ø4 M5

Figure: A M5 Figure: B M5 Figure: C M5
Ø4 Ø4 Ø4

Figure: D M5 Figure: E M5 Figure: F M5
Ø4 Ø4 Ø4

Figure: G M5 Figure: H M5 Figure: I M5
Ø4 Ø4 Ø4

Figure: J Figure: K Figure: L
