FOOT PEDALS 3

MATERIALS FOR ALL “PED” VALVES aluminium 11S Temperature range: max + 60°C
Body: shock resistant plastic material
Protection cover: 7.5mm Working pressure: 2 ... 10 bar
Nominal orifice:
Fluid: 50µ filtered lubricated

or non lubricated air

3/2 COMPACT FOOT PEDAL 5/2 FOOT PEDAL

without Protective Cover

CODE DESCRIPTION SYMBOL € CODE DESCRIPTION SYMBOL €

N17 N17

PED304M 3/2” Spring Return 4mm Fittings 2 28.37 PEDS502M 5/2” G1/4” Spring Return 52.46
1
PEDS502B 5/2” G1/4” Bi-stable 55.86

5/2 FOOT PEDAL ELECTRIC FOOT PEDAL

with Protective Cover

Utillization power, according to IEC 337-1

DC AC
V 24 220 V 24 220 380 500
A 6 0.1 A 10 10 8 6

Life time (cycles) 10.000.000
Contact resistance 25 mΩ
Electrical protection degree IP 54
Contacts 1 NO + 1 NC rapid switch

* Spring Return

CODE DESCRIPTION SYMBOL € CODE DESCRIPTION SYMBOL €

N17 N17

PED502M 5/2” G1/4” Spring Return 65.00 01.087.0 NO-NC Contacts 34.74

PED502B 5/2” G1/4” Bi-stable 65.00 01.088.0 NO-NC Contacts 38.50

PED502S Safety Foot Pedal 5/2” G1/4”* 65.00

with Safety Featured
