3 SOLENOID CONTROL VALVES

5/3 SOLENOID VALVE PRESSURISED CENTRES 5/3 SOLENOID VALVE PRESSURISED CENTRES

G1/8 Ports G1/4 Ports

Note: Solenoid Coils must be ordered separately Note: Solenoid Coils must be ordered separately

CODE DESCRIPTION SYMBOL € CODE DESCRIPTION SYMBOL €
P06
P06 7020022300 5/3” G1/4” PC 97.23

7010022300 5/3” G1/8” PC 86.80

SOLENOID COIL

CODE NOMINAL POWER INPUT TYPE €

W0215000101 VOLTAGE INRUSH HOLDING P40
W0215000111
W0215000121 24VDC 2W 2W 22 Ø8 BA 2W-24VDC 11.04
W0215000131 11.04
24V 50/60Hz 4VA 3VA 22 Ø8 BA 3V-24VAC 11.04
11.04
110V 50/60Hz 4VA 2W 22 Ø8 BA 3VA-110VAC

220V 50/60Hz 4VA 2W 22 Ø8 3VA-220VAC

CODE DESCRIPTION

M1NS2000 Form B Socket Connector SEE SECTION 9 FOR PRICING

TECHNICAL DATA
• Voltage tolerances: -10% to +15%
• Insulation class: F155
• Degree of protection: IP65 -DIN 40050
• Solenoid rating: 100%
• Operating temperature range: -20°C to +120°C
• Electric contact: AMP DIN 43650 2 contacts + 1 earth
• Max temperature at 100% solenoid rating: 70°C at 20°C ambient temperature

MANIFOLDS

G1/8” Ports G1/4” Ports

CODE DESCRIPTION € CODE DESCRIPTION €

0223000201 2 Position P06 0224000201 2 Position P06
0223000301 3 Position 0224000401 4 Position
0223000401 4 Position 36.65 0224000501 5 Position 40.90
0223000501 5 Position 47.96 0224000601 6 Position 64.23
0223000601 6 Position 54.34 0224000701 7 Position 76.82
0223000701 7 Position 64.96 0226005500 Blanking Plate Size 1/4” 87.50
0226004500 Blanking Plate Size 1/8” 77.93 100.19
77.93 2.68
