ACCESSORIES FOR ISO VALVES 3

SOLENOID COILS FOR ISO 5599/1 VALVES

22mm

CODE DESCRIPTION € • Voltage tolerance: -10% +15%
• Insulation class: F155
W0215000101 24VDC P40 • Degree of protection: IP65 EN60529 with connector
W0215000111 24VAC • Avoid prolonged exposure to the atmospheric agents
W0215000121 110VAC 11.04 • Coil temperature 100% ED: from 70˚C to 20˚C
W0215000131 220VAC 11.04 - Ambient temperature
11.04
11.04

CODE DESCRIPTION

M1NS2000 Form B Socket Connector SEE SECTION 9 FOR PRICING

SOLENOID COILS FOR ISO 5599/2 VALVES

30mm

CODE DESCRIPTION €
P40 • Voltage tolerance: -10% +15%
W0210010100 24VDC • Insulation class: F155
W0210011100 24VAC 9.93 • Degree of protection: IP65 EN60529 with connector
W0210012100 110VAC 9.93 • Avoid prolonged exposure to the atmospheric agents
W0210013100 220VAC 9.93 • Coil temperature 100% ED: from 70˚C to 20˚C

9.93 - Ambient temperature

CODE DESCRIPTION

G1NU2000 Form A Socket Connector SEE SECTION 9 FOR PRICING

SUB-BASES

ISO 5599/1 Valves €

CODE DESCRIPTION P06

0228000150 Pos. 1 Manifold Base - Side Ports 22.41
0228000155 Pos. 2 Manifold Base - Bottom Ports 22.41
0228000200 Pos. 3 Input End-Plate 9.62
0228000210 Pos. 5 Blind End-Plate 4.84
0228000300 Pos. 6 Intermediate Plate - Top Ports 11.95
0228000301 Pos. 7 Intermediate Plate - Back Ports 11.95
0228000500 Pos. 8 Blanking Plate 5.03
0228000400 Pos. 9 Intermediate Diaphragm 1.15
0228000100 Pos. 11 Indivdual Base - Side Ports 12.47
0228000700 Pos. 13 Assembly Kit 2.00

ISO 5599/2 Valves €

CODE DESCRIPTION P06

0228001150 Pos. 1 Manifold Base - Side Ports 27.40
0228001155 Pos. 2 Manifold Base - Bottom Ports 27.40
0228001200 Pos. 3 Input End-Plate 12.21
0228001210 Pos. 5 Blind End-Plate 7.85
0228001300 Pos. 6 Intermediate Plate - Top Ports 15.46
0228001301 Pos. 7 Intermediate Plate - Back Ports 15.46
0228001500 Pos. 8 Blanking Plate 6.16
0228001400 Pos. 9 Intermediate Diaphragm 1.90
0228001100 Pos. 11 Indivdual Base - Side Ports 19.93
0228001700 Pos. 13 Assembly Kit 2.62
