2 STAUFF CONNECT - DIN2353 FITTINGS
STRAIGHT FEMALE STUD FITTING
TYPE FI-GA-...-R • SERIES L
L1
S1 S2
T1
D2
1
L3
L2
L
SERIES L - FEMALE WHITWORTH PARALLEL PIPE THREAD (BSPP)
CODE Description Codes Tube PN Dimensions [mm] Weight2 €
Fitting body supplied with OD [mm] [bar] [kg] ca. A05
cutting ring & union nut D1 Thread T1 D2 L L11 L2 L3 S1 S2 per 100
3.2 2.12
6010001221 FI-GA-06LR-W3-MS 6 315 G 1/8" 4 26.0 34.0 19.0 12 14 14 5.3 11.30
14 6.0 2.32
6010001252 FI-GA-06LR1/4-W3-MS 6 315 G 1/4" 4 31.0 39.0 24.0 18 19 17 8.4 8.21
17 6.1 2.51
6010001223 FI-GA-08LR-W3-MS 8 315 G 1/4" 6 31.0 39.0 24.0 17 19 19 8.9 13.04
19 7.8 20.91
6010001224 FI-GA-08LR3/8-W3-MS 8 315 G 3/8" 6 31.0 39.0 24.0 16 24 22 9.9 3.09
22 10.3 11.01
6010001226 FI-GA-10LR-W3-MS 10 315 G 1/4" 8 32.0 40.0 25.0 17 19 22 14.6 4.25
27 16.8 5.65
6010001227 FI-GA-10LR3/8-W3-MS 10 315 G 3/8" 8 32.0 40.0 25.0 16 24 32 28.1 8.40
36 38.8 21.54
6010001229 FI-GA-12LR1/4-W3-MS 12 315 G 1/4" 8 33.0 41.0 26.0 17 19 41 70.8 33.85
50 80.1 37.09
6010001230 FI-GA-12LR-W3-MS 12 315 G 3/8" 10 33.0 41.0 26.0 17 24 60
6010001231 FI-GA-12LR1/2-W3-MS 12 315 G 1/2" 10 37.0 45.0 30.0 20 27
6010001232 FI-GA-15LR-W3-MS 15 315 G 1/2" 12 38.0 46.0 31.0 20 27
6010001234 FI-GA-18LR-W3-MS 18 315 G 1/2" 15 38.0 47.0 30.5 20 27
6010001235 FI-GA-22LR-W3-MS 22 160 G 3/4" 19 43.0 52.0 35.5 22 36
6010001236 FI-GA-28LR-W3-MS 28 160 G 1" 25 45.5 54.5 38.0 24.5 41
6010001237 FI-GA-35LR-W3-MS 35 160 G 1 1/4" 30 51.5 62.5 41.0 26.5 55
6010001238 FI-GA-42LR-W3-MS 42 160 G 1 1/2" 36 53.5 62.5 42.5 28.5 60
SERIES S - FEMALE WHITWORTH PARALLEL PIPE THREAD (BSPP)
CODE Description Codes Tube PN Dimensions [mm] Weight2 €
Fitting body supplied with OD [mm] [bar] [kg] ca.
cutting ring & union nut D1 Thread T1 D2 L L11 L2 L3 S1 S2 per 100 A05
6010001239 FI-GA-06SR-W3-MS 6 630 G 1/4" 4 33.0 41.0 26.0 17 19 17 6.7 4.25
6010001241 FI-GA-08SR-W3-MS 8 630 G 1/4" 5 33.0 41.0 26.0 17 19 19 7.3 4.39
6010001242 FI-GA-10SR-W3-MS 10 630 G 3/8" 7 34.0 43.0 26.5 17 24 22 11.0 5.60
6010001244 FI-GA-12SR-W3-MS 12 630 G 3/8" 8 34.0 43.0 26.5 17 24 24 11.7 5.80
6010001246 FI-GA-14SR-W3-MS 14 630 G 1/2" 10 40.0 50.0 32.0 20 27 27 17.1 10.04
6010001247 FI-GA-16SR-W3-MS 16 630 G 1/2" 12 40.0 50.0 31.5 20 27 30 18.5 7.83
6010001248 FI-GA-20SR-W3-MS 20 400 G 3/4" 16 45.0 56.0 34.5 22 36 36 33.3 12.94
6010001249 FI-GA-25SR-W3-MS 25 400 G 1" 20 49.5 61.5 37.5 24.5 41 46 70.1 25.20
6010001250 FI-GA-30SR-W3-MS 30 400 G 1 1/4" 25 55.5 68.5 42.0 26.5 55 50 78.4 34.39
6010001251 FI-GA-38SR-W3-MS 38 400 G 1 1/2" 32 59.5 74.5 43.5 28.5 60 50 100.6 40.77
1 Approximate dimension with nut tightened.
2 Weight including cutting ring and union nut.
