2 CLAMPS STANDARD POLYPROPYLENE
CLAMPS - GROUP 7
STANDARD POLYPROPYLENE
CLAMPS - GROUP 6 MANUFACTURED TO DIN3015

MANUFACTURED TO DIN3015

COMPLETE CLAMPS COMPLETE CLAMPS

CODE DESCRIPTION OD € CODE DESCRIPTION OD €
mm mm
A10 A10

1110000817 SP 644,5 PP-DP-AS M W10 44.5 4.92 1110000826 SP 757,2 PP-DP-AS M W10 57.2 8.20

1110000819 SP 648,3 PP-DP-AS M W10 48.3 4.92 1110000827 SP 760,3 PP-DP-AS M W10 60.3 8.20

1110000821 SP 650,8 PP-DP-AS M W10 50.8 4.92 1110000828 SP 763,5 PP-DP-AS M W10 63.5 8.20

1110000823 SP 654,0 PP-DP-AS M W10 54.0 5.17 1110000829 SP 770 PP-DP-AS M W10 70.0 8.20

1110007156 SP 773 PP-DP-AS M W10 73.0 8.20

1110000830 SP 776,1 PP-DP-AS M W10 76.1 8.20

JAWS X 2 JAWS X 2

CODE DESCRIPTION OD € CODE DESCRIPTION OD €
mm mm
A10 A10

1130003551 644,5 PP 44.5 2.61 1130006216 757,2 PP 57.2 3.69
1130003554 648,3 PP 1130006221 760,3 PP
1130003560 650,8 PP 48.3 2.61 1130006226 763,5 PP 60.3 3.69
1130003563 654 PP 1130006230 770 PP
50.8 2.61 1130008666 773 PP 63.5 3.69
1130006234 776,1 PP
54.0 2.85 70.0 3.69

73.0 4.00

76.1 3.69

TOP PLATE TOP PLATE

CODE DESCRIPTION € CODE DESCRIPTION €

A10 A10

1130000273 DP 6 W3 0.57 1130001501 DP 7 W3 1.96

WELD PLATE WELD PLATE

CODE DESCRIPTION € CODE DESCRIPTION €

A10 A10

1120001175 SP 6 M W2 1.53 1120001180 SP 7 M W2 2.23

BOLTS X 2 BOLTS X 2

CODE DESCRIPTION € CODE DESCRIPTION €

A10 A10

1130004025 AS-M6X70-DIN931/933-8.8-W3 0.19 1130004026 AS-M6X100-DIN931/933-8.8-W3 0.21
