HEAVY DUTY POLYPROPYLENE CLAMPS 2
CLAMPS - GROUP 7S
Mounting Rail and
MANUFACTURED TO DIN3015 Hexagon Rail Nut

COMPLETE CLAMPS

CODE DESCRIPTION OD € STAUFF Mounting Rail, type TS 11/14/30 is
mm suitable for use with all Twin Series and
A10 Standard Series group sizes. The Hexagon
Rail Nut, type SM is to be used in conjunction
1110002579 SPAL 7065 PP-DPAL-AS M W12 65.0 37.81 with the STAUFF Mounting Rail.

1110002580 SPAL 7070 PP-DPAL-AS M W12 70.0 37.81 Channel Rail Adaptor

1110002582 SPAL 7073 PP-DPAL-AS M W12 73.0 39.46

1110002583 SPAL 7075 PP-DPAL-AS M W12 75.0 37.81

1110002584 SPAL 7076,1 PP-DPAL-AS M W12 76.1 37.81

1110002587 SPAL 7080 PP-DPAL-AS M W12 80.0 37.81

1110002588 SPAL 7082,5 PP-DPAL-AS M W12 82.5 37.81

1110002589 SPAL 7088,9 PP-DPAL-AS M W12 88.9 37.81

JAWS X 2 The STAUFF Channel Rail Adaptor, type CRA
is suitable for use with various channel rails,
CODE DESCRIPTION OD € including types from Halfen, Hilti, Unistrut®
mm and STAUFF Cushion Clamp series.
A10
Materials
1130006183 7065 PP 65.0 16.58
1130006187 7070 PP Unless otherwise stated, all metal parts (e.g.
1130006191 7073 PP 70.0 16.58 weld plates, cover plates, bolts, rail nuts, etc.)
1130006192 7075 PP are made of Carbon Steel St37. All metal parts
1130006196 7076,1 PP 73.0 18.22 are available in Stainless Steel:
1130006200 7080 PP
1130006203 7082,5 PP 75.0 16.58 Stainless Steel V2A
1130006211 7088,9 PP • Material Code: W4
76.1 16.58
Stainless Steel V4A
80.0 16.58 • Material Code: W5

82.5 16.58 Surface Finishings

88.9 16.58 Unless otherwise stated, all metal parts
made of Carbon Steel St37
TOP PLATE DESCRIPTION € are available with the following standard
CODE surface finishings:
A10
1130000722 DPAL 7 S W2 Untreated
6.22 • Material Code: W1

WELD PLATE DESCRIPTION € Phosphated
CODE SPAL 7 S M W2 • Material Code: W2
A10
1120001956 Zinc/Nickel-plated
12.90 • Material Code: W3

BOLTS X 2 DESCRIPTION € Individual combinations of alternative materials
CODE and surface finishes are available upon request.
A10 Consult us for further information.
1130004186 M16X130
1.93
