STANDARD SERIES FRL - “NEW DEAL” 5

DISTRIBUTION BLOCK

CODE DESCRIPTION €

P11

9200401 G1/8” for G1/4 Units 18.83
28.29
9400401 G1/4” for G3/8 - G1/2 Units 55.00

9600401 G1/2” for G3/4 - G1 Units

Max. working temperature at 10 bar 50 °C
Max. admissible pressure 18 bar

A B C D E F G H (n°2pos.) L
G 1/4” 42 42 15 34 34 8.5 8.5 21 M4 Hole
G 3/8” 60 60 20 49 49 14 14 30 M4 Hole
G 1/2” 60 60 20 49 49 14 14 30 M4 Hole
G 3/4” 80 80 30 64 64 16 16 40 M6 Hole
G 1” 80 80 30 64 64 16 16 40 M6 Hole

DRIP LEG DRAIN

CODE PORT €

P11

4589003 G1/2” 74.71

Threaded port G1/2” System supply condensate drain:
Max. working temperature at 10 bar 50 °C • All-round condensate level viewing
Max. admissible pressure 18 bar • Automatic drain from inside the bowl
Wall fixing screws M6x75 • Axial coupling

MOUNTING HARDWARE AUTOMATIC DRAIN

CODE DESCRIPTION SIZE € CODE DESCRIPTION SIZE €

P11 P11

9200701 Mounting Bracket G1/4” 3.76 9000801 Fully Automatic G3/8” - G1” 37.96

9400701 for Regulator G3/8” - G1/2” 5.08 9000803 Semi Automatic G1/4” - G1/2” 16.22

9200601 Spacer for G1/4” 6.30 9255201 Metal Bowl for G1/4” 18.98

9400601 Wall Mounting G3/8” - G1/2” 6.94 9455201 use with Semi G3/8” - G1/2” 23.08

9600601 FRL G3/4” 12.60 Automatic Drain

SPARE FILTER ELEMENT SHUT-OFF VALVE ADAPTOR

CODE DESCRIPTION € CODE DESCRIPTION €

P11 P11

9250103 4 Micron for Filter G1/4” 10.57 9201001 for Shut-Off Valve G1/4” 0.89
10.57 0.94
9250102 20 Micron for Filter G1/4” 13.77 9401001 for Shut-Off Valve G3/8” 1.08
13.77
9450103 4 Micron for Filter G3/8” - G1/2” 19.21 9401002 for Shut-Off Valve G1/2” 267
19.21
9450102 20 Micron for Filter G3/8” - G1/2” 48.22

9650103 4 Micron for Filter G3/4” - G1”

9650102 4 Micron for Filter G3/4” - G1”

9450105 Coalescing Oil Removal Filter
