P. 103
HOSE COUPLING INSERTS 2
METRIC FEMALE - 24° O’RING CONE - LIGHT DUTY
CODE HOSE THREAD (F) MM H L S O’RING BAR PSI €
Dia
2020025043 A02
2020025044 1/4" M12 x 1.5 6 23 51 17 5x1 280 4000
2020025045 3.56
2020025046 1/4" M14 x 1.5 8 22 50 17 6 x 1.5 280 4000 1.34
2020025047 1.78
2020025048 1/4" M16 x 1.5 10 24 52 19 7.5 x 1.5 280 4000 2.44
2020025049 1.43
2020025050 1/4" M18 x 1.5 12 24 52 22 9 x 1.5 280 4000 2.26
2020025051 3.87
2020025052 5/16" M16 x 1.5 10 24 52 19 7.5 x 1.5 280 4000 1.47
2020025053 3.13
2020025054 5/16" M18 x 1.5 12 24 52 22 9 x 1.5 280 4000 2.26
2020025055 3.18
2020025056 3/8" M16 x 1.5 10 23 54 19 7.5 x 1.5 280 4000 3.39
2020025057 6.52
2020025058 3/8" M18 x 1.5 12 24 54 22 9 x 1.5 280 4000 7.79
2020025059 3.47
2020025060 3/8" M22 x 1.5 15 24 54 27 12 x 2 280 4000 7.95
11.43
1/2" M22 x 1.5 15 24 57 27 12 x 2 280 4000 20.78
1/2" M26 x 1.5 18 26 59 32 15 x 2 210 3000
5/8" M26 x 1.5 18 27 62 32 15 x 2 210 3000
5/8" M30 x 2 22 28 64 36 20 x 2 210 3000
3/4" M26 x 1.5 18 34 75 32 15 x 2 210 3000
3/4" M30 x 2 22 31 71 36 20 x 2 210 3000
1" M36 x 2 28 32 83 41 26 x 2 165 2400
1 1/4" M45 x 2 35 36 94 50 32 x 2.5 100 1450
1 1/2" M52 x 2 42 37 102 60 38 x 2.5 100 1450
METRIC FEMALE - 24° O’RING CONE - HEAVY DUTY
CODE HOSE THREAD (F) MM H L S O’RING BAR PSI €
Dia
2020025063 A02
2020025064 1/4" M14 x 1.5 6 23 51 17 5 x 1 450 6500
2020025065 3.87
2020025066 1/4" M16 x 1.5 8 22 50 19 6 x 1.5 450 6500 1.70
2020025067 2.04
2020025068 1/4" M18 x 1.5 10 24 52 22 7.5 x 1.5 450 6500 2.84
2020025069 2.72
2020025070 1/4" M20 x 1.5 12 24 52 24 9 x 1.5 450 6500 2.44
2020025071 4.70
2020025072 5/16" M18 x 1.5 10 24 52 22 7.5 x 1.5 350 5000 2.22
2020025073 2.87
2020025074 5/16" M20 x 1.5 12 24 52 24 9 x 1.5 350 5000 4.35
2020025075 2.87
2020025076 3/8" M18 x 1.5 10 25 55 22 7.5 x 1.5 445 6500 4.57
2020066079 6.74
2020025077 3/8" M20 x 1.5 12 24 54 24 9 x 1.5 445 6500 8.13
2020025078 7.81
2020025079 3/8" M22 x 1.5 14 28 58 27 10 x 2 445 6500 10.48
2020025080 10.60
2020025081 1/2" M22 x 1.5 14 28 61 27 10 x 2 415 6000 26.12
20.59
1/2" M24 x 1.5 16 29 62 30 12 x 2 415 6000 44.98
5/8" M30 x 2 20 33 69 36 16.3 x 2.4 350 5000
3/4" M30 x 2 20 36 76 36 16.3 x 2.4 350 5000
3/4" M36 x 2 25 38 78 46 20.3 x 2.4 350 5000
3/4" M36 x 2 25 38 78 41 20.3 x 2.4 350 5000
1" M36 x 2 25 40 91 46 22 x 2 280 4000
1" M42 x 2 30 40 91 50 25.3 x 2.4 280 4000
1 1/4" M42 x 2 30 41 99 50 25.3 x 2.4 210 3000
1 1/4" M52 x 2 38 45 103 60 33.3 x 2.4 210 3000
1 1/2" M52 x 2 38 46 110 60 33.3 x 2.4 185 2700
