P. 105
HOSE COUPLING INSERTS 2
90° METRIC SWEPT ELBOW - 24° O’RING CONE - LIGHT DUTY
* Swaged nut
** Tieffe nut
CODE HOSE THREAD (F) MM H L K S1 O’RING BAR PSI €
Dia
2020025085 A02
2020025086 1/4" M12 x 1.5 6 26 53 26 17 5 x 1 280 4000
2020025087 6.96
2020025088 1/4" M14 x 1.5 8 29 57 29 17 6 x 1.5 280 4000 2.77
2020025089 2.92
2020025090 1/4" M16 x 1.5 10 29 57 30 19 7.5 x 1.5 280 4000 4.90
2020025091 3.04
2020025092 1/4" M18 x 1.5 12 29 57 32 22 9 x 1.5 280 4000 4.30
2020025093 5.92
2020025094 5/16" M16 x 1.5 10 31 59 33 19 7.5 x 1.5 280 4000 2.92
2020025095 5.69
2020025096 5/16" M18 x 1.5 12 28 56 32 22 9 x 1.5 280 4000 4.22
2020025097 8.17
2020025098 3/8" M16 x 1.5 10 31 61 31 19 7.5 x 1.5 280 4000 6.48
2020025099 14.70
2020025100 3/8" M18 x 1.5 12 31 61 33 22 9 x 1.5 280 4000 36.73
2020025101 9.17
2020025102 3/8" M22 x 1.5 15 31 61 35 27 12 x 2 280 4000 14.95
26.12
1/2" M22 x 1.5 15 37 70 38 27 12 x 2 280 4000 51.15
1/2" M26 x 1.5 18 37 70 40 32 15 x 2 210 3000
5/8" M26 x 1.5 18 44 80 45 32 15 x 2 210 3000
5/8" M30 x 2 22 44 80 47 36 20 x 2 210 3000
3/4" M26 x 1.5 18 54 94 57 32 15 x 2 210 3000
3/4" M30 x 2 22 54 94 52 36 20 x 2 210 3000
1" M36 x 2 28 70 121 66 41 26 x 2 165 2400
1 1/4" M45 x 2 35 84 141 83 50 32 x 2.5 100 1450
1 1/2" M52 x 2 42 100 164 100 60 38 x 2.5 100 1450
90° METRIC SWEPT ELBOW - 24° O’RING CONE - HEAVY DUTY
CODE HOSE THREAD (F) MM H L K S1 O’RING BAR PSI €
Dia
2020025105 A02
2020025106 1/4" M14 x 1.5 6 25 53 26 17 5 x 1 450 6500
2020025107 5.92
2020025108 1/4" M16 x 1.5 8 29 57 29 19 6 x 1.5 450 6500 3.09
2020025109 3.56
2020025110 1/4" M18 x 1.5 10 29 57 30 22 7.5 x 1.5 450 6500 5.73
2020025111 5.48
2020025112 1/4" M20 x 1.5 12 29 57 32 24 9 x 1.5 450 6500 4.11
2020025113 8.47
2020025114 5/16" M18 x 1.5 10 31 59 33 22 7.5 x 1.5 350 5000 3.83
2020025115 6.49
2020025116 5/16" M20 x 1.5 12 28 56 32 24 9 x 1.5 350 5000 8.56
2020025117 5.30
2020025118 3/8" M18 x 1.5 10 30 61 33 22 7.5 x 1.5 445 6500 8.17
2020066080 13.43
2020025119 3/8" M20 x1 .5 12 31 61 33 24 9 x 1.5 445 6500 13.08
2020025120 12.34
2020025121 3/8" M22 x 1.5 14 34 64 37 27 10 x 2 445 6500 23.03
2020025122 20.91
2020025123 1/2" M22 x 1.5 14 39 71 41 27 10 x 2 415 6000 47.72
44.33
1/2" M24 x 1.5 16 39 71 42 30 12 x 2 415 6000 98.82
5/8" M30 x 2 20 44 80 49 36 16.3 x 2.4 350 5000
3/4" M30 x 2 20 54 94 55 36 16.3 x 2.4 350 5000
3/4" M36 x 2 25 54 94 57 46 20.3 x 2.4 350 5000
3/4" M36 x 2 25 54 94 57 41 20.3 x 2.4 350 5000
1" M36 x 2 25 70 121 70 46 22 x 2 280 4000
1" M42 x 2 30 70 121 66 50 25.3 x 2.4 280 4000
1 1/4" M42 x 2 30 84 141 84 50 25.3 x 2.4 210 3000
1 1/4" M52 x 2 38 84 141 80 60 33.3 x 2.4 210 3000
1 1/2" M52 x 2 38 100 164 101 60 33.3 x 2.4 185 2700
HYDRAULIC PIPEWORK, COMPONENTS & ACCESSORIES
