P. 109
HOSE COUPLING INSERTS 2
STRAIGHT FLANGE (ISO 61 FLANGE END)
CODE HOSE FLANGE H L A BAR PSI €
I.D. SIZE
2020066140 1/2" 1/2" 47.0 80.0 A02
2020066141 1/2" 5/8" 47.0 80.0
2020066142 1/2" 3/4" 47.0 80.0 30.2 350 5000 8.52
2020066143 5/8" 1/2" 48.0 84.0
2020066144 5/8" 5/8" 48.0 84.0 34.0 350 5000 39.16
2020066145 5/8" 3/4" 48.0 84.0
2020066146 3/4" 1/2" 49.5 90.0 38.1 350 5000 13.99
2020066148 3/4" 1" 54.0 94.5
2020066149 1" 3/4" 55.0 106.0 30.2 350 5000 24.94
2020066150 1" 1" 55.0 106.0
2020066151 1" 1 1/4" 55.0 106.0 34.0 350 5000 19.68
2020066152 1" 62.0 120.0
2020066153 1 1/4" 1 1/4" 62.0 120.0 38.1 350 5000 23.55
2020066154 1 1/4" 1 1/2" 62.0 120.0
2020066155 1 1/4" 1 1/2" 67.5 132.0 30.2 350 5000 27.64
2020066156 1 1/2" 2" 67.5 132.0
2020066157 1 1/2" 2" 70.0 140.0 44.5 350 5000 12.17
2020066158 2 1/2" 80.0 150.0
2" 38.1 280 4000 26.43
2"
44.5 280 4000 13.27
50.8 280 4000 18.60
44.5 210 3000 60.07
50.8 210 3000 19.25
60.3 210 3000 27.81
60.3 185 2700 31.21
71.4 185 2700 38.98
71.4 175 2500 46.74
84.1 175 2500 81.78
Komatsu style flange
45° FLANGE ELBOW (ISO 61 FLANGE END)
CODE HOSE FLANGE H L K A BAR PSI €
I.D. SIZE
5000 A02
2020066159 1/2" 1/2" 47 80 20 30.2 350 5000
5000 13.60
2020066160 1/2" 5/8" 48 81 22 34.0 350 5000 25.66
5000 19.43
2020066161 1/2" 3/4" 51 84 24 38.1 350 5000 35.87
5000 26.11
2020066165 5/8" 1/2" 51 87 21 30.2 350 5000 34.55
5000 30.41
2020066166 5/8" 5/8" 53 89 22 34.0 350 4000 14.08
4000 16.95
2020066167 5/8" 3/4" 55 91 24 38.1 350 4000 39.64
3000 18.67
2020066168 3/4" 1/2" 64 104 26 30.2 350 3000 25.34
3000 75.36
2020066169 3/4" 3/4" 62 102 25 38.1 350 2700 28.47
2700 44.98
2020066170 3/4" 1" 64 104 27 44.5 350 2500 45.55
2500 63.80
2020066171 1" 3/4" 80 131 30 38.1 280 63.88
104.22
2020066172 1" 1" 77 128 28 44.5 280
2020066173 1" 1 1/4" 77 128 28 50.8 280
2020066174 1 1/4" 1" 94 152 37 44.5 210
2020066175 1 1/4" 1 1/4" 88 146 32 50.8 210
2020066176 1 1/4" 1 1/2" 88 146 32 60.3 210
2020066177 1 1/2" 1 1/2" 105 169 37 60.3 185
2020066178 1 1/2" 2" 105 169 37 71.4 185
2020066179 2" 2" 144 214 55 71.4 175
2020066180 2 2 1/2" 142 212 53 84.1 175
Komatsu style flange
