HOSE COUPLING INSERTS 2

SAE J518 SPLIT FLANGE HALF - 3000 PSI

CODE SIZE A B C D E F I €

A02

2020066359 1/2" 54.0 23.0 38.1 8.75 8.7 20 13 5.77

2020066360 3/4" 65.0 26.0 47.6 10.5 11.1 22 14 6.30

2020066361 1" 52.4 29.2 52.4 10.5 13.1 22 16 6.37

2020066362 1 1/4" 58.7 36.3 58.7 12.0 15.1 22 14 7.56

2020066363 1 1/2" 69.9 41.1 69.9 13.5 17.9 24 16 8.63

2020066364 2" 77.8 48.2 77.8 13.5 21.4 26 16 12.01

SAE J518 SPLIT FLANGE HALF - 6000 PSI

CODE SIZE A B C D E F I €

A02

2020066366 1/2" 57 24 40.5 8.75 9.1 22 16 6.21

2020066367 3/4" 72 30 50.8 10.5 11.9 28 19 6.84

2020066368 1" 81 35 57.2 13.0 13.9 32 24 8.95

2020066369 1 1/4" 96 39 66.7 15.0 15.8 38 27 11.66

2020066371 1 1/2" 113 48 79.4 17.0 18.3 42 30 22.56

2020066372 2" 134 57 96.8 21.0 22.2 52 37 31.98

WASHCLEANER FEMALE - “FK” TYPE

CODE HOSE THREAD H L D O’RING €
I.D. (F)
2020000999 1/4" 34.8 62.8 A02
2020051569 5/16" M22x1.5 37.8 65.8
2020049832 3/8" M22x1.5 37.8 68.3 14 10x2 4.30
M22x1.5
14 10x2 4.35

14 10x2 4.18
