2 HOSE COUPLING INSERTS

45° METRIC STANDPIPE - ONE PIECE

CODE HOSE E H L K M BAR PSI €
Dia
A02
2020000956 1/4" 6 48.0 77.0 24.0 21 280 4000
3.91
2020000980 1/4" 8 48.0 76.5 24.0 23 450 6500 3.26
3.52
2020000988 1/4" 10 49.5 78.0 25.5 25 450 6500 5.26
4.38
2020000991 1/4" 12 50.5 79.0 26.5 25 450 6500 4.42
3.65
2020031203 5/16" 10 51.5 80.0 27.5 25 350 5000 3.56
4.06
2020066092 5/16" 12 57.5 86.0 27.5 25 350 5000 6.25
5.87
2020001156 3/8" 10 62.0 92.5 27.5 22 350 5000 4.48
4.70
2020001165 3/8" 12 62.5 93.0 28.5 25 445 6500 6.56
7.61
2020001170 3/8" 14 64.5 95.0 30.5 28 445 6500 7.17
12.25
2020001174 3/8" 15 61.5 92.5 27.5 24 280 4000 31.79
9.25
2020001305 1/2" 14 73.5 106.5 34.0 28 415 6000 9.91
9.65
2020001308 1/2" 15 70.5 103.5 31.0 24 280 4000 12.39
15.43
2020001311 1/2" 16 74.0 107.0 34.5 29 415 6000 21.73
30.12
2020001316 1/2" 18 72.0 105.0 32.5 26 210 3000 32.64
34.25
2020001412 5/8" 18 86.5 122.5 34.0 26 210 3000 34.03
65.56
2020001415 5/8" 20 92.5 128.5 40.5 35 350 5000

2020001420 5/8" 22 85.5 121.5 33.0 28 210 3000

2020066093 3/4" 18 94.5 135.5 41.0 26 210 3000

2020001528 3/4" 20 100.5 141.5 47.0 35 350 5000

2020001533 3/4" 22 96.0 137.0 42.5 28 210 3000

2020001536 3/4" 25 103.5 144.5 50.0 39 350 5000

2020001631 1" 25 131.0 186.0 63.0 39 280 4000

2020001634 1" 28 124.0 178.0 56.0 29 165 2400

2020001637 1" 30 126.5 181.5 58.5 43 280 4000

2020001710 1 1/4" 30 152.5 213.5 69.0 43 210 3000

2020001713 1 1/4" 35 153.0 214.0 69.0 35 125 1800

2020001715 1 1/4" 38 156.0 217.0 72.5 48 210 3000

2020001763 1 1/2" 38 184.0 254.0 79.0 48 185 2700

2020066094 1 1/2" 42 175.0 246.0 71.0 36 100 1450
