MINI-CYLINDERS ISO 6432 ACCESSORIES 3

FOOT MOUTING PISTON ROD NUT

ISO 6432 Cylinders ISO 6432 Cylinders

CODE TO SUIT € CODE TO SUIT THREAD €

P03 P03

W0950080001 10mm Cylinder 2.65 W0950080011 10 M4 0.77

W0950120001 12/16mm Cylinder 3.13 W0950120011 16 M6 0.77

W0950200001 20/25mm Cylinder 3.27 W0950200011 20 M8 0.97

W0950322010 25 M10 x 1.25 1.21

FLANGE MOUNTING FORK CLEVIS

ISO 6432 Cylinders ISO 6432 Cylinders

CODE TO SUIT € CODE TO SUIT THREAD €

P03 P03

W0950080002 10mm Cylinder 2.65 W0950080020 10 M4 2.02

W0950120002 12/16mm Cylinder 3.13 W0950120020 12 - 16 M6 2.02

W0950200002 20/25mm Cylinder 4.11 W0950200020 20 M8 2.34

W0950322020 25 M10 x 1.25 3.50

COUNTER SUPPORT SPHERICAL EYE MOUNTING

ISO 6432 Cylinders ISO 6432 Cylinders

CODE TO SUIT € CODE TO SUIT THREAD €

P03 P03

W0950080005 10 3.58 W0950080025 10 M4 16.61

W0950120005 12/16 4.46 W0950120025 12 - 16 M6 16.61

W0950200005 20/25 4.55 W0950200025 20 M8 18.56

W0950322025 25 M10x1.25 21.14

CYLINDER HEAD NUT REED SWITCH AND CLAMP

ISO 6432 Cylinders ISO 6432 Cylinders

CODE TO SUIT THREAD € CODE DESCRIPTION €

P03 P03

W0950080010 10 M12 x 1.25 0.77 W0950000201 Reed Switch 28.39
2.55
W0950120010 16 M16 x 1.5 0.77 W0950000510 Bracket for Ø10 Cylinder 2.55
2.55
W0950200010 25 M22 x 1.5 1.26 W0950000512 Bracket for Ø12 Cylinder 2.55
2.55
W0950000516 Bracket for Ø16 Cylinder
183
W0950000520 Bracket for Ø20 Cylinder

W0950000525 Bracket for Ø25 Cylinder
