4 MODULAR FRL SERIES BLOCK ASSEMBLY CLIP

AUTOMATIC DRAIN

CODE DESCRIPTION € CODE DESCRIPTION €

X01 X01

AASS23 18270 09352 Fully Automatic 59.83 AS1 R412014758 For All Units 2.02
2.95
AS2 R412006371 For All Units 4.22
5.97
AS3 R412007371 For All Units

AS5 R412009371 For All Units

MOUNTING CLIP MOUNTING PLATE

CODE DESCRIPTION € CODE DESCRIPTION €

X01 X01

AS1 R412014757 For All Units 3.55 A­ S1 R412014755 For All Units 4.96
5.42 5.87
AS2 R412006370 For All Units 6.74 AS2 R412006368 For All Units 7.99
7.88 14.18
AS3 R412007370 For All Units AS3 R412007368 For All Units

AS5 R412009370 For All Units AS5 R412009368 For All Units

PRESSURE GAUGE BACK ENTRY

CODE Ø CONNECTION SCALE RANGE €

mm THREAD bar X01

1827231048 40 G1/8” 0-2.5 12.03

1827231018 40 G1/8” 0-6 12.03

1827231024 40 G1/8” 0-10 12.03

DESIGN 1827231009 40 G1/8” 0-16 12.03

• Bourdon tube pressure gauge. 1827231059 40 G1/4” 0-6 12.03
• Housing: plastic
• Scales: bar = green, 1827231060 40 G1/4” 0-10 12.03
psi = white.
Background = black. 1827231047 40 G1/4” 0-16 12.03
Pointer = white.
1827231023 50 G1/4” 0-1.6 12.03

1827231012 50 G1/4” 0-2.5 12.03

1827231016 50 G1/4” 0-6 12.03

TECHNICAL SPECIFICATIONS 1827231015 50 G1/4” 0-10 12.03
Ambient temperature 50°C bar max
Temperature of medium 50°C bar max 1827231010 50 G1/4” 0-16 12.03

1827231011 63 G1/4” 0-16 12.03
