3 PRESSURE & VACUUM SWITCHES

ADJUSTABLE PRESSURE SWITCH ADJUSTABLE PRESSURE SWITCH

Push-On Terminals DIN43650 Connector

CODE THREAD PRESSURE RATING € CODE THREAD PRESSURE RATING €

PMN1A-14K BSP bar E03 BSP bar E03
PMN2A-14K PSM2
PMN10A-14K G1/4” 0.1-1 28.49 G1/4” 0.2-2 79.47
PMN20A-14K PSM10
G1/4” 0.2-2 28.49 G1/4” 2-10 79.47
PSM50
G1/4” 2.10 28.49 G1/4” 10-50 85.66

G1/4” 10-20 28.49

PNEUMATIC PRESSURE SWITCH ADJUSTABLE VACUUM SWITCH

DIN43650 Connector Push-On Terminals

CODE THREAD PRESSURE RATING € CODE THREAD PRESSURE RATING €

BSP bar E03 BSP bar E03
PSA2-R14 VCN2A-14K
G1/4” 0.2-2 73.20 G1/4” -200 to -900 mBar 36.53
PSA10-R14
G1/4” 1-10 73.20

ADJUSTABLE VACUUM SWITCH RUBBER CAP

DIN43650 Connector

CODE THREAD PRESSURE RATING € CODE SIZE €

BSP bar E03 E03
VSM1-T
G1/4” -100 to -500 mbar 97.87 31060-RC for PMN & VCN Switches 2.36
VSM2-T
G1/4” -500 to -900 mbar 97.87

FIXED TEMPERATURE SWITCH

CODE SET TEMPERATURE THREAD CONTACTS €

BSP E03

NTB25BA 25 G3/8” Open 46.33

NTB25CA 25 G1/2” Open 46.33

NTB31BA 31 G3/8” Open 46.33

NTB31CA 31 G1/2” Open 46.33

USE NTB38BA 38 G3/8” Open 46.33
The bimetal fixed temperature switches
series NTB have been designed to satisfy the NTB38CA 38 G1/2” Open 46.33
most different requirements of temperature
controlling in various applications as NTB47BA 47 G3/8” Open 46.33
hydraulics, lubrication, transmission systems
and so on. They have been designed with an NTB47CA 47 G1/2” Open 46.33
anodized aluminium body, G3/8” or G1/2”
thread connection, a fixed temperature NTB60BA 60 G3/8” Open 46.33
sensor from 25˚C to 105˚C housed inside the
thermostat and a PG09 DIN 43650 cable clamp NTB60CA 60 G1/2” Open 46.33
connector.
NTB70BA 70 G3/8” Open 46.33
Once installed the temperature switch on the
machine to be checked, it is possible to rotate NTB70CA 70 G1/2” Open 46.33
and place the contact carrier body and the
connector in the position required. NTB80BA 80 G3/8” Open 46.33

NTB80CA 80 G1/2” Open 46.33

NTB90BA 90 G3/8” Open 46.33

NTB90CA 90 G1/2” Open 46.33

NTB100BA 100 G3/8” Open 46.33

NTB100CA 100 G1/2” Open 46.33

NTB105BA 105 G3/8” Open 46.33

NTB105CA 105 G1/2” Open 46.33
