3 AIR KNIVES AND AMPLIFIERS

NEUBLADE AIRSTRIP

NOT ALL COMPRESSED AIR PRODUCTS ARE THE SAME....

The NEUBLADE from Beckair utilises innovative APPLICATIONS
technology developed to give the highest
performance, lowest noise and lowest air DRYING Printing, Paints, Coatings, Components, Conveyor
consumption compared to any other product. Belts
The powerful, whisper-quiet blade of air is ideal for
drying, cleaning, cooling or containing in all kinds of CLEANING Components, Conveyors, Instruments Lens,
process, food and manufacturing applications. Dust Removal, Waste Removal

The key to it’s performance is our flow straightening COOLING Components
technology (Patent applied for) which provides an
exceptionally laminar sheet of air. The low levels of AIR CURTAIN Fume Containment,
turbulence also mean extremely low noise (65dB). Heat Containment from
ovens and furnaces

l No moving parts - means the Neublade is maintenance free
l Ultra low air consumption means significantly lower running costs than standard nozzles and strips
l Ultra-Quiet Operation (typically 65 dB) for an improved working environment
l Easily mounted onto existing installations
l Choice of air entry for maximum flexibility

TECHNICAL INFORMATION - NEUBLADE

CODE LENG TH INLET A IR CONSUMPTI ON@4BAR NOISE €

mm inches SLPM SCFM DB(A) @1M E26

BNEUBLADE/80 80 3” 1/4” BSP + Push In Fitting 198 7 65 111.04

BNEUBLADE/150 150 6” 1/4” BSP + Push In Fitting 368 13 65 145.73

BNEUBLADE/300 300 12” 1/4” BSP + Push In Fitting 736 26 65 184.60

BNEUBLADE/450 450 18” 1/4” BSP + Push In Fitting 1104 39 65 235.11

BNEUBLADE/600 600 24” 1/4” BSP + Push In Fitting 1471 52 65 275.92

BNEUBLADE/750 750 30” 1/4” BSP + Push In Fitting 1839 65 65 340.04

BNEUBLADE/900 900 36” 1/4” BSP + Push In Fitting 2207 78 65 384.74

BNEUBLADE/1000 1000 39” 1/4” BSP + Push In Fitting 2462 87 65 437.20

BNEUBLADE/1200 1200 48” 1/4” BSP + Push In Fitting 2943 104 65 503.26

The Neublade is manufactured from extruded, anodised aluminium and comes complete with quick fit hose connector.
Because of the method of construction, we are able to offer the Neublade in any length up to 2m long.
Please call our sales team for further information.

HOW NEUBLADE CAN REDUCE YOUR OPERATING COSTS

TYPE OF AIRSTRIP AIR CON SUMPTION@4BAR NOISE LEVEL POWER REQUIRED RU NNING COSTS
kW PER YEAR*
SLPM SCFM dB(A)@1m

5 Holes in 50mm length of Pipe

(3mm or 1/8” 1980 70 95 10.0 £960

Standard Air Wipe (50mm) 450 16 85 2.3 £220

Neublade (50mm) 124 4.5 65 0.65 £62

*Based on 40 hours per week, 48 weeks per year with an energy cost of around £0.05 per kWh
