STAUFF CONNECT - DIN2353 FITTINGS 2

L1 MALE STUD ELBOW

S2 TYPE FI-WE-...-Rk • SERIES LL
S1

L3
i

D2
D1

SERIES LL • WHITWORTH TAPER PIPE THREAD (BSPT) D3
T

L2

L

CODE Description Codes Tube PN Dimensions [mm] Weight2 €
Fitting body supplied with OD [mm] [bar] [kg] ca.
cutting ring & union nut D1 Thread T D2 D3 i L1 L11 L2 L3 S1 S2 per 100 A05

6010000861 FI-WE-04LLRk-W3-MS 4 100 R1/8 keg. 3.0 3.0 8.0 15.0 21.0 11.0 17 9 10 1.7 4.10

6010000863 FI-WE-06LLRk-W3-MS 6 100 R1/8 keg. 4.5 4.5 8.0 15.0 21.0 9.5 17 9 12 1.8 4.25

6010000864 FI-WE-08LLRk-W3-MS 8 100 R1/8 keg. 6.0 6.0 8.0 17.0 23.0 11.5 20 12 14 2.5 4.68

Endless Opportunities SCNToEAnWUn!FeFct

Tube Fitting Technology by STAUFF

24° tube fittings and accessories made from carbon steel the premium Zinc/Nickel coating sets a new benchmark in
complement the extensive range of original STAUFF terms of corrosion protection. Get yourself convinced of
components for fluid power applications from own outstanding product quality and increased operational safety
development and manufacturing. Due to the careful and reliability for your machines and equipment, and
selection and processing of materials, pressure ratings as experience the advantages of single-sourcing all hydraulic
defined in the DIN/ISO standards can even be exceeded; pipework components from the manufacturer.

HYDRAULIC PIPEWORK, COMPONENTS & ACCESSORIES
